Technical specifications

Workspindle dia

mm

100

Spindle taper

ISO 50

Spindle speed range

RPM

10-1800

Main motor power

kW

20

Table cross travel X

mm

1,200

Headstock vertical travel Y

mm

1,120

Column longitudinal travel Z

mm

950

Spindle stroke W

mm

630

Table clamping surface

mm

1,000 x 1,120

Table load

Kg

3,000

Feeds X, Y, Z, W

mm.min^-1

4 – 3,000

Rapid traverse for X, Y, Z, W

mm.min^-1

8,000

Total power consumption

kVA

50

Machine weight

kg

13,000
